Drapery Measurement Finder

Plastic Pinch Pleat Curtain C Rings Hooks Metal Curtain Eyelet Rings Set

Drapery Measurement Finder

Step 1

What style of drape hanging header would you like?

Choose One

Soft Top Style
Soft Top No pleats on top. Apply for 4-in-1, Hook belt, Flat hook, Tab top, Tie Top, Rod pocket, and Back tab. Consider fullness for width.
Pleated or Ripple Fold Style
Pleated or Ripple Fold For a structured, modern look. Apply for Pinch pleat, Tailor pleat, Goblet, Inverted box pleated, Tape pleat, Triple pleat, Riple fold, Cylindrical goblet.
Suitable for straight curtain rods. If curtain rods are irregular or track rods, please contact us to help you recommend the size.
Grommet Style
Grommet For a structured, modern look.
Step 2

Do you have a drapery rod installed already?

Choose One

Rod Installed YES I have a rod installed already
No Rod Installed NO I don't have a rod installed yet

(For more accurate measurement, we strongly recommend you have the rod or track installed)

Step 3

What's your rod length?

Curtain rod length measurement diagram
inch
Step 4

What's the height from bottom tip of rod to floor

Curtain height measurement diagram
inch
Step 5

Do you want single or split panels?

Choose One

Single Panel Single Panel
Split Panels Split Panels
Step 6

What kind of finished look would you like for your drapes?
Choose fullness based on that.

Choose One

Step 6

What kind of finished length would you like for your drapes?

Choose One

1 inch ABOVE FLOOR 1 inch ABOVE FLOOR
BREAK ON FLOOR BREAK ON FLOOR
SLIGHT PUDDLE ON FLOOR SLIGHT PUDDLE ON FLOOR
Step 5

What kind of finished length would you like for your drapes?

Choose One

1 inch ABOVE FLOOR 1 inch ABOVE FLOOR
BREAK ON FLOOR BREAK ON FLOOR
SLIGHT PUDDLE ON FLOOR SLIGHT PUDDLE ON FLOOR
Step 7

Your Curtain Measurement Results

Selected style: --
Drapery rod status: --
Panel type: --
Fullness ratio: --
Finished length: --
Recommended size: --
Step 3

What's your window width? (Frame outer edge to edge.)

Window width measurement diagram
inch
Step 4

How many inches beyond your window frame would the rod extend?

Rod extension measurement diagram
inch
inch
Step 5

What's the height from window top to floor?

Window to floor height measurement diagram
inch
Step 6

How many inches above the window frame would you mount the rod?

Rod mounting height measurement diagram
inch
Step 7

Do you want single or split panels?

Choose One

Single Panel Single Panel
Split Panels Split Panels
Step 8

What kind of finished look would you like for your drapes?
Choose fullness based on that.

Choose One

Step 8

What kind of finished length would you like for your drapes?

Choose One

1 inch ABOVE FLOOR 1 inch ABOVE FLOOR
BREAK ON FLOOR BREAK ON FLOOR
SLIGHT PUDDLE ON FLOOR SLIGHT PUDDLE ON FLOOR
Step 9

What kind of finished length would you like for your drapes?

Choose One

1 inch ABOVE FLOOR 1 inch ABOVE FLOOR
BREAK ON FLOOR BREAK ON FLOOR
SLIGHT PUDDLE ON FLOOR SLIGHT PUDDLE ON FLOOR
Step 9

Your Curtain Measurement Results

Selected style: --
Drapery rod status: --
Panel type: --
Fullness ratio: --
Finished length: --
Recommended size: --

For Pleat Heading Style

Step 1: Measure the Curtain Rod Width and Placement

If you have installed a curtain rod, measure the length of the rod.

If a curtain rod is not installed, first check where the curtain rod will be installed above and to the sides of the window frame. Consider how high you want the rod to be to create the desired visual effect.

Height Above the Window Frame: Curtain rods are usually mounted 6-10 inches above the window frame to give the impression of a taller window. Lightly mark this height with a pencil or use masking tape as a guide.

Width Beyond the Window Frame: To allow room for the curtain stack, extend the rod 6-15 inches beyond each side of the window frame. Lightly mark these spots with a pencil or use masking tape as a guide.

Cordless Roman Shade in natural light

Step 2: Know INOUTZCURT's Standard Fullness

To prevent your drapes from looking flat like a stretched sheet, it’s important to consider adding fullness for extra width.

Pleated Styles

The fabric’s fullness is already factored into the design. We use 160-200% fabric fullness to create the pleats, ensuring the curtains have a rich and luxurious appearance.

1.6x Fullness for pinch pleat, tailored pleat, inverted pleat, and goblet styles.

2x Built-in Fullness for pinch pleat, tailor pleat, inverted pleat, and goblet style.

2.3x Built-in Fullness for triple pleat and triple tailor pleat style.

Cordless Roman Shade in natural light

Step 3: Determine The Width And Length of The Curtains

Liner shading guide

For Soft Top & Grommet Heading Style

The default fullness is set at 100%, but for drapes, you should aim for a fullness of 160-200% of the final measured width. A 160% fullness will give a more tailored look, while 200% fullness, which is recommended, will create a richer, more luxurious appearance. Here's a quick guide on recommended fullness:

1.6 times of the curtain rod length is a moderate gather.

2 times of the curtain rod length is a standard gather.

You'll need to choose the fullness ratio based on the type of header you're using. Additionally, you'll need to determine how many panels are necessary to achieve your desired fullness, as the fullness ratio can vary depending on the header style.

1.0X Fullness

1.0X Fullness

1.5X Fullness

1.5X Fullness

2.0X Fullness

2.0X Fullness

Soft top

Soft top

grommet

grommet

Determine The Width of Curtains

· For Pleated Style, Single Panel Width = Rod Track Full Length / Panel Quantity

· For Soft Top Style, Single Panel Width = (Rod Track Full Length x 200% fullness) / Panel Quantity

· For Grommet Style, Single Panel Width = (Rod Track Full Length x 200% fullness) / Panel Quantity

· For Ripple Fold Style, Single Panel Width = Rod Track Full Length / Panel Quantity

grommet

Finding The Perfect Fit

Different lengths of curtains will give the room a different visual experience.

grommet

Tips

· Your customized curtains will be made to the exact width and length you specify.

· Heading styles include French Pleat, Triple French Pleat, Tailor Pleat, Triple Tailor Pleat, and Flat Hooks, all of which come with adjustable hooks and rings.

· ·Both width and length are measured with a steel tape measure and accurate to within 1 inch.

· Be sure to measure each window and doorway individually.
